不锈钢电梯门套的做法要注意什么?

来源:http://www.sddtmt.com/ 浏览:0发表时间:2023-04-24
不锈钢电梯门口袋的方法:为木板架打下良好的基础,包裹不锈钢折叠板。
The method for stainless steel elevator door pockets: lay a good foundation for the wooden frame and wrap it with stainless steel folding boards.
安装:如果门套采用传统的现场制作方式,则由现场装修人员用钉子直接固定在门套的门套本体上;但如果是门套安装的整套门产品(现在越来越多的用户使用整套门产品),应考虑两个问题:
Installation: If the door pocket adopts the traditional on-site production method, the on-site decoration personnel will directly fix it to the door pocket body with nails; But if it is a complete door product installed with a door pocket (more and more users are using the entire door product now), two issues should be considered:
一、对应成套门产品的门套技术结构是否符合作为成套门产品所要求的牢固、准确、稳定三大技术特性;
1、 Whether the technical structure of the door cover corresponding to the complete set of door products meets the three major technical characteristics of firmness, accuracy, and stability required as a complete set of door products;
二、整套门套安装人员在安装现场的事先勘察和安装过程中工艺流程的规范化(如使用发泡剂等方法可能对门套的牢固性、准确性和今后的使用稳定性都有可能产生影响)。
2、 The installation personnel of the entire set of door jambs shall conduct preliminary investigation on the installation site and standardize the process flow during the installation process (such as using foaming agents and other methods may have an impact on the firmness, accuracy, and future stability of the door jambs).
1、根据设计图纸检查门的规格、开启方向及相关附件。
1. Check the specifications, opening direction, and related accessories of the door according to the design drawings.
临沂电梯门套上门安装
2、用卷尺测量门洞的高度和宽度。门的标准高度和宽度为200cm×80cm;卫生间门的高度和宽度为200cm×70cm。如尺寸有出入,应及时纠正。
2. Measure the height and width of the door opening with a tape measure. The standard height and width of the door is 200cm × 80cm; The height and width of the bathroom door are 200cm × 70cm。 If there is any discrepancy in size, it should be corrected in a timely manner.
3、测量位置线,确定门框的位置,用墨棒拉出垂直线,一侧门洞有两条垂直线。
3. Measure the position line, determine the position of the door frame, and use an ink stick to pull out the vertical line. There are two vertical lines in one side of the door opening.
4、用冲击钻在垂直线上钻孔。这些洞之间的距离大约是30厘米。一扇侧门的两排有10个孔。冲击钻钻头为12mm,钻孔深度约6cm。
4. Drill holes on vertical lines using an impact drill. The distance between these holes is approximately 30 centimeters. There are 10 holes in the two rows of a side door. The impact drill bit is 12mm and the drilling depth is about 6cm.
5、用锤子把小木楔一个一个地钉进洞里,固定门框板。楔子尺寸为5cm×1.5cm×1.5cm,由落叶松制成。落叶松木材结构紧密,不易松动。
5. Use a hammer to nail small wooden wedges one by one into the holes and fix the door frame plate. Wedge size is 5cm × 1.5cm × 1.5cm, made of larch. The structure of larch wood is tight and not easy to loosen.
6、切割材料制成门框。左右侧门框龙骨木板尺寸为200cm×3cm×8cm,门框顶龙骨木板尺寸为80cm×3cm×8cm。将高密度9cm板粘在龙骨上,用汽枪钉固定。
6. Cut the material to make the door frame. The size of the left and right door frame keel board is 200cm × 3cm × 8cm, the size of the keel board on the top of the door frame is 80cm × 3cm × 8cm。 Stick the high-density 9cm board onto the keel and fix it with an air gun nail.
7、根据门的形状将三个门框连接起来,用大钉子固定在接缝处。
7. Connect the three door frames according to the shape of the door and fix them at the joints with large nails.
8、用平面将连接的门框表面打磨光滑,边角修剪干净。
8. Polish the surface of the connected door frame smooth with a flat surface, and trim the edges and corners clean.
9、将门框放在门洞上,根据墙的水平线,在门框下垫上木块或砖块,调整门框的高度。地下预留5cm,埋于地板龙骨内。
9. Place the door frame on the door opening, and according to the horizontal line of the wall, place wooden or brick blocks under the door frame to adjust the height of the door frame. Reserve 5cm underground and bury it in the floor keel.
10、在门框顶部钉上钉子,挂好铅垂线,通过铅垂线调整门框垂直度,测量时用扭钉将门框固定在门洞上。
10. Nail the top of the door frame with a nail, hang a plumb line, adjust the verticality of the door frame through the plumb line, and fix the door frame to the door opening with a twist nail during measurement.
11、做门面线。门面可根据图纸从箱中取出或由施工人员制作。生产完成后,将门面固定在门框六上,使门套基本完成。
11. Make a facade line. The facade can be taken out of the box according to the drawings or made by construction personnel. After the production is completed, fix the door surface on the door frame 6, so that the door pocket is basically completed.
12、将门放在门套上,确定铰链在门套上的具体位置,然后根据铰链的厚度切出口径。同时切断锁套的直径。将车门安装到门套上,并用螺丝刀拧紧铰链的螺钉。
12. Place the door on the door pocket, determine the specific position of the hinge on the door pocket, and then cut the aperture according to the thickness of the hinge. Simultaneously cut off the diameter of the lock sleeve. Install the door onto the door pocket and tighten the hinge screws with a screwdriver.
本文由临沂电梯门套上门安装提供帮助,更多的相关内容请点击 http://www.sddtmt.com希望本文能够为您带来帮助,感谢您的阅读!
This article provides assistance for the installation of Linyi elevator door covers. For more related content, please click on http://www.sddtmt.com I hope this article can be helpful to you. Thank you for reading!
