大理石电梯门套施工工艺要注意什么!

来源:http://www.sddtmt.com/ 浏览:0发表时间:2023-03-07
基层墙面处理-壁钻打槽-镀锌线或铜线与线连接,装配线-大理石板安装-注浆-裂纹-清洗-全面的清洁-综合检查和验收。
Base course wall treatment - wall drilling and grooving - connection of galvanized wire or copper wire with wire, assembly line - marble slab installation - grouting - crack - cleaning - comprehensive cleaning - comprehensive inspection and acceptance.
三、大理石电梯门套施工步骤
3、 Construction steps of marble elevator door pocket
石材选型:用比色法对石材的颜色进行选择和分类。安装在同一表面的石材的颜色应一致。
Stone selection: use colorimetric method to select and classify the color of stone. The color of stones installed on the same surface shall be consistent.
墙基清洗:清洗墙壁,安装底座支架。同时,执行结构套筒,查找规则,弹出垂直线和水平线。根据设计图纸和实际需要,弹出安装石材的位置线和砌块线。(stone5A石研究协会
Wall base cleaning: clean the wall and install the base bracket. At the same time, execute the structural sleeve, find the rules, and pop up the vertical and horizontal lines. According to the design drawings and actual needs, snap the location line and block line for the installation of stones. (stone5A Stone Research Association
阵容:根据大小,一个好的建筑,提前石材安装前与经纬仪两垂直线下面,更好在500px的位置从大角,为了检查竖线挂的准确,确保顺利安装,控制线上下。
拉丝不锈钢电梯
Line up: According to the size, a good building should be installed under the two vertical lines of the theodolite before the stone is installed in advance, preferably from the large angle at the position of 500px. In order to check the accuracy of the vertical line and ensure the smooth installation, control the line and the line.
安装底部托架,并将预置支架安装在楼板上,按照上平线安装。支架要支撑牢固,便于相互连接,也可以和架在一起,支架后,沿着支架的方向,将长50毫米厚木板在同一水平面动,以确保在同一水平面上的石材。
Install the bottom bracket, install the preset bracket on the floor, and install it according to the upper horizontal line. The support shall be firmly supported to facilitate mutual connection, and can also be connected with the support. After the support, the 50 mm thick board shall flow on the same horizontal plane along the direction of the support to ensure the stone on the same horizontal plane.
安装连接部件:用设计中指定的不锈钢螺栓固定角钢和平板钢板。调整平钢板的位置,使平钢板的孔与石板的插入孔重合,固定扁钢板并扣紧扳机。
Install connecting parts: fix angle steel and flat steel plate with stainless steel bolts specified in the design. Adjust the position of the flat steel plate so that the hole of the flat steel plate coincides with the insertion hole of the stone plate, fix the flat steel plate and tighten the trigger.
大理石装饰板式安装:根据凹槽和部件找到一个好的位置,底板可放置在墙角处。
Marble decorative plate installation: find a good position according to the groove and parts, and the base plate can be placed at the corner of the wall.
面板微调:安装大理石装饰板,调节水位。如果板上嘴不均匀,则可将相应的双股铜线垫放置在连接在板底下端的平板钢板上。调整垂直度,调整面板顶部的不锈钢接头与墙壁之间的间隙,直到面板垂直。
Panel fine adjustment: install marble decorative plate to adjust the water level. If the mouth on the plate is uneven, the corresponding double-stranded copper wire pad can be placed on the flat steel plate connected to the lower end of the plate bottom. Adjust the verticality, and adjust the gap between the stainless steel joint on the top of the panel and the wall until the panel is vertical.
的顶部装饰板块安装:的顶部板水平,除了按照一般石材安装要求安装好,裂缝的结构和板悬挂长度为20毫米厚板条,板条的平面板上的250毫米,吊点可以连接在铁。可以用彩色铝线悬挂木棒,在木杆挂起后,即在石板与墙面之间填满,并填紧实,防止注浆渗漏。
Installation of top decorative plate: the last top plate is horizontal. In addition to being installed according to general stone installation requirements, the crack structure and plate suspension length are 20mm thick slats, and 250mm on the flat plate of Flat noodles. The lifting point can be connected to iron. The wooden rod can be hung with colored aluminum wire. After the wooden rod is hung, it is filled between the stone slab and the wall, and filled tightly to prevent grouting leakage.
清洗大理石表面:去除大理石表面的防污污垢,用棉线擦拭石材。
Clean the marble surface: remove the anti-fouling dirt on the marble surface, and wipe the stone with cotton thread.
大理石电梯门套使用越来越多,不仅要按正确的方法工作,以后还要注意保养,这样才能延长电梯门套的使用寿命。
Marble elevator door jambs are used more and more. Not only should we work in the correct way, but also pay attention to maintenance in the future, so as to extend the service life of elevator door jambs.
有了不锈钢电梯门套上面的小总结,希望对广大客户有所帮助,如果有什么不理解的或者寻求帮助的请点击我们的网站:http://www.sddtmt.com或者来电咨询,我们会尽全力为您解决
With the summary above the stainless steel elevator door pocket, I hope it can help our customers. If you have any questions or need help, please click our website: http://www.sddtmt.com Or call for consultation, and we will do our best to solve it for you
