电梯不锈钢门套具体安装制作过程

来源:http://www.sddtmt.com/ 浏览:0发表时间:2022-06-21
根据设计图纸检查门的规格、开启方向、相关配件等。
Check the specification, opening direction and relevant accessories of the door according to the design drawings.
用卷尺量门洞的高与宽。门的标准高宽尺寸是200cm×80cm;卫生间的门高宽是200cm×70cm。尺寸如有出入要及时纠正。
Measure the height and width of the door opening with a tape measure. The standard height and width of the door is 200cm × 80cm; The height and width of the toilet door is 200cm × 70cm。 If there is any discrepancy in size, it should be corrected in time.
测量位置线,确定门框的位置,用墨斗弹拉出垂直线,一侧门洞两条垂直线。
Measure the position line, determine the position of the door frame, pull out the vertical line with an ink fountain, and two vertical lines of the door opening on one side.
在垂直线上用冲击钻打眼,孔眼与孔眼之间的距离约为30cm,一侧门两排共10个孔眼。冲击钻的钻头应为12mm,所钻孔眼深度约为6cm。
Drill holes on the vertical line with an impact drill. The distance between the holes is about 30cm. There are 10 holes in two rows of one side door. The drill bit of impact drill should be 12mm, and the depth of the drilled hole is about 6cm.
将小木楔用铁锤逐个钉入孔眼,以便固定门框板。小木楔的体积大小为5cm×1.5cm×1.5cm,以落叶松制作的为好,因为落叶松的木质结构紧,不容易松动。
Hammer the small wooden wedges into the holes one by one to fix the door frame plate. The volume of the small wooden wedge is 5cm × 1.5cm × 1.5cm, it is better to make larch, because the wood structure of larch is tight and not easy to loosen.
开料制作门框。左右做两侧门框龙骨的木工板尺寸为200cm× 3cm×8cm,门框顶龙骨的木工板尺寸为80cm×3cm×8cm。将高密度九厘板涂胶粘在龙骨上,再用钉固定。
Cut materials to make door frames. The dimension of the wood board used to make the keels of the door frames on both sides is 200cm ×  3cm × 8cm, the dimension of the wood board of the keel on the top of the door frame is 80cm × 3cm × 8cm。 Glue the high-density 9cm board on the keel and fix it with nails.
将制作好的三条门框按门的形状连接起来,并且用大钉子在接合处固定。
Connect the three fabricated door frames according to the shape of the door, and fix them at the joint with big nails.
用刨子将连接好的门框表面修平整,修整边角,棱角分明。
Use a plane to flatten the surface of the connected door frame, trim the edges and corners, and make the edges and corners clear.
将门框放到门洞上,按墙面的水平线为准,门框下拿木头或者砖头垫起,调节门框的高度。下面预留5cm埋在地板的龙骨中。
Put the door frame on the door opening, subject to the horizontal line of the wall, take wood or bricks under the door frame to pad up, and adjust the height of the door frame. 5cm is reserved below and buried in the keel of the floor.
在门框的上面钉一个钉子,把线垂挂上,通过线垂来调整门框的垂直,一边衡量一边用麻花钉将门框固定在门洞上。
Nail a nail on the door frame, hang the line vertically, adjust the verticality of the door frame through the line sag, and fix the door frame on the door opening with fried dough twist nails while measuring.
制作门脸的线条。门脸可以是现成买的,也可以是施工人员按照图纸做出来的。制作完成后,就把门脸固定到门框上六,这样门套就基本完成了。
Make the lines of the door face. The facade can be bought off the shelf or made by the construction personnel according to the drawings. After making, fix the door face to the door frame six, so that the door pocket is basically completed.
把门放到门套上比划好,确定合页在门套上的具体位置,再按合页的厚度切出口径。也切出锁套的口径。将门安装到门套上,合页用锣丝刀将锣丝钉拧紧。注意门与门套的间隙不得大于1.5mm,以顺畅开关门为准。
Put the door on the door pocket, make a comparison, determine the specific position of the hinge on the door pocket, and then cut the caliber according to the thickness of the hinge. Also cut out the diameter of the lock sleeve. Install the door on the door pocket, and use a gongs knife to tighten the gongs and screws on the hinge. Note that the gap between the door and the door pocket shall not be greater than 1.5mm, subject to the smooth opening and closing of the door.
门套表面的附着物及灰尘,然后涂腻子。在涂腻子前先在门脸与墙面之间贴上美文纸,防止喷涂油漆时沾到墙面上。涂腻子时一定要均匀,修补好门套上钉眼。
Remove the attachments and dust on the surface of the door pocket, and then apply putty. Before applying putty, paste paper between the door face and the wall to prevent it from sticking to the wall when spraying paint. The putty must be applied evenly, and the nail holes on the door jamb must be repaired.
喷涂油漆。油漆喷涂效果会更加细腻一点,而细部可用刷子涂刷。
Spray paint. The paint spraying effect will be more delicate, and the details can be brushed with a brush.
将锁安装到锁孔上,小心不要弄坏油漆。
Install the lock on the lock hole and be careful not to damage the paint.
电梯不锈钢门套起到了固定门扇,同时对墙角进行保护的作用,并且还能发挥良好的装饰性效果,是当前相当受欢迎的一种门套。制作安装的过程上面已经介绍非常详细了,每一步都有相应的要求,精心制作出来的门套,不仅质量好,而且装饰性效果也不错。
The stainless steel door pocket of elevator plays the role of fixing the door leaf, protecting the wall corner at the same time, and can also play a good decorative effect. It is a very popular door pocket at present. The production and installation process has been introduced in great detail above, and each step has corresponding requirements. The carefully made door pocket is not only of good quality, but also of good decorative effect.
